||Assuming that you read my
last article from January 2009 Professional Imagemaker, you should know how
to set up and light a Shirley test. The purpose of this test is to determine
whether or not your camera ISO, or you could say its sensitivity rating, is
correct and whether or not your handheld meter is accurate to your camera.
In addition to this, a Shirley test will provide you with a perfectly
exposed image from which a custom pre-set for RAW processing can be created
for the future processing of all your RAW files.
Having a pre-set is important as stated in the previous article since it
gives you a standard to light to.
'Well that’s all fine and dandy,' you say, 'but I’m just coming out of a
long cold wet/snowy winter and I’ve had just about enough of your technical
articles on Lighting for Digital with their ugly setup images, I want to see
something beautiful'. To which I reply, 'Well maybe you are ready for a
little photographic antipasto, how about a look at some images I recently
took in tropical Hawaii of some beautiful semi-clad women?' Now before you
call me a sexist you should know that most of the scantily clad creatures
that I have had an opportunity to light and photograph have been well-built,
male firefighters and considering that I’m a healthy heterosexual male
photographer, I’m thinking that it's time to balance myself out so that I
can be an equal-opportunity sexist. Besides I believe that a high percentage
of men get into photography just so that they can use photography as an
excuse to get close to some great looking women and so why should I be any
Anyhow take a look at bathing-suit models Blake Schaeffer in Image 1 and
Kara Duenasin Image 3. I should also mention that Hawaii was very cloudy for
the seven days that I was shooting there and so I had to create my own
sunlight, as depicted in the setup diagrams Image 2 and Image 4. Hopefully
the fact that I didn’t really get to escape winter fully (overcast skies in
Hawaii) will help you to hate me a bit less. Anyhow once you’ve finished
admiring Blake and Kara I think we should push on with Lighting For Digital.
Assuming that the Shirley set is set up and ready to go (see Image 05), it's
time to photograph it. The camera aperture you choose is somewhat arbitrary;
I like to work with an aperture that makes sense with the power of the
light-source in use. For practical purposes the aperture should not be too
close to the extreme ends of the lens’ available aperture choices.
The aperture setting should provide enough depth of field to keep the test
targets and subject in focus. In this test I used the middle aperture on the
lens, f11. In this test the camera is set to f11 at 1/60 and the power of
the strobe head in the soft-box is adjusted accordingly. The shutter-speed
at 1/60 is slow enough for the camera shutter sync with flash or strobe
lighting, yet fast enough to overpower the ambient light in my studio. For
this test the camera must be set to M for manual rather than any of the auto
settings – Program, Auto, Aperture Priority, and Shutter Priority.
As you know I’m all about control and so I am a big advocate of shooting
manual with a handheld meter, but if you must shoot using autoexposure
modes, shoot your test on manual as described and then go back to your usual
auto-exposure setting once the test is done; more on how to integrate the
test results with auto settings later.
The ISO setting on the camera to be tested should be set to the sensitivity
or ISO you are going to use when shooting. I have selected 100 ISO since
that is the ISO I use on this camera 99% of the time. Interestingly enough,
you will probably find that you will only need to do the test for one ISO
setting and the results will be applicable to all other ISO choices on that
camera. If you include a hand-held meter in the test, so that you can check
to see if the strobe is emitting the same volume of light each time, make
sure that it is set to the same ISO setting as the camera ISO setting. By
the way, using a hand-held incident meter to set exposure for the test
assumes that you will be manually setting exposure on your camera and that
the meter is accurate (see sidebar entitled 'Sunny 16' Test).
'Sunny 16' Test: Here’s a quick and dirty test to check the accuracy of your
light meter called the 'Sunny 16 Test'– point the dome of your hand-held
incident meter directly at the mid-day sun with no clouds between you and
the sun, then dial your shutter-speed setting until it matches your ISO
setting, if the meter is correctly calibrated it should read f16. If not
then adjust accordingly with the plus/minus calibration adjustment controls
that most prometers have.
To meter the main-light source, make sure you point the dome of the handheld
incident meter directly towards it; the meter’s dome should be completely
bathed in light from that source of illumination, which means that you will
see no shadows on the dome. If it is not pointed directly at the main source
of illumination, if instead you are pointing the meter’s dome at the camera
lens or some other direction, you are going to be averaging the shadow with
the main-light rendering incorrect readings that will somewhat over-expose
the fully lit subject areas. To control the amount of light striking your
test subjects when using flash or strobe, either dial-in the correct
brightness with the unit’s power variable control, or alter the light’s
distance to the subject, or use a combination of the two. If you are
lighting your test with 'constant light-sources' such as sunlight, open-sky,
tungsten, fluorescent, LED, or HMI, you can 'dial in' their brightness for
your required aperture by changing shutter speed; remember, the sun doesn’t
come equipped with a rheostat. Once the lighting is set, check and double
check using incident meter readings to ensure that the lighting is even over
the Shirley test subjects from edge to edge. Since I am setting my camera to
f11 for this test, every incident meter reading I take over the subject area
must read exactly f11 – not f8 9/10ths or f11 1/10th, but f11 exactly.
Before I can start capturing my Shirley test images, I set my camera to RAW
and I set the appropriate colour or white balance for the set or scene by
choosing from one of the pre-sets, or better still, by performing a custom
white balance. Even though white balance can be set after capture in your
RAW processing software, setting White
I’m A Little Confused
1/3 Stop Exposure Bracket: · 1st Exposure – Set aperture to F16 and fire to
capture an image that should be one stop under-exposed.
· 2nd Exposure – Set aperture to f14 (f11 2/3) and fire to capture an image
that should be2/3 of a stop under-exposed.
· 3rd Exposure – Set aperture to f12 (f11 1/3) and fire to capture an image
that should be 1/3 of a stop under-exposed.
· 4th Exposure – Set aperture to F11 and fire to capture what should be a
correctly exposed image.
· 5th Exposure – Set aperture to f10 (f8 2/3) and fire to capture an image
that should be 1/3 of a stop over-exposed.
· 6th Exposure – Set aperture to f9 (f8 1/3) and fire to capture an image
that should be 2/3 of a stop over-exposed.
· 7th Exposure – Set aperture to f8 and fire to capture an image that should
be one stop overexposed.
